LLM chat system design is where teams lose the room in five minutes if they jump to boxes. I open with behavior, numbers, and failure modes, then draw services. Same order every time.
I am Ayabonga Qwabi, AI specialist and cloud architect based in South Africa. If you need this built rather than sketched, AI integration and cloud work is the lane I ship in.
What you are designing (text-only slice)
This article sticks to English text so token limits, moderation, and latency stay honest.
Users need to:
- start and continue a conversation
- send messages and read model replies
- list, open, and delete threads
- rate answers with thumbs up or down (stored as signals; training pipelines are a later program)
Non-functional requirements to state out loud
Say these before anyone draws a rectangle:
- Latency: multi-second answers can be acceptable if you explain context size, tools, and streaming.
- Security: identity, authorization, audit trails on stored turns.
- Rate limits: per user, per IP, and per API key so one noisy client cannot starve shared inference.
- Scale: web tier scales separately from the model pool.
Envelope math for LLM chat system design interviews
When nobody has production metrics, I still put numbers on the board:
- 10M daily active users
- 5 conversations per user per day
- 4 user turns and 4 assistant turns per conversation (8 persisted messages per conversation)
That order of magnitude is ~200M messages per day on write-heavy paths if you log everything.
At ~100 bytes average metadata per message (text plus ids and timestamps, not big attachments), you are in the tens of GB per day of append traffic. Multi-year retention means sharded storage and retention policy, not one hot partition.
High-level architecture for a chat LLM product
I put a thin experience layer (BFF or gateway) in front of mobile and web so auth, versioning, and orchestration stay in one place.
Services I usually draw:
- Conversation service: threads, list, delete, append turns
- Safety gate: small classifier or rules plus optional hosted moderation
- Inference adapter: prompt assembly, tools, caps, routing to the model fleet
- Durable store: conversation id, role, body, timestamps, model metadata
Happy-path sequence for one message
Why moderation runs before the big model
If there is no path to a useful answer, I do not burn GPU. A cheap gate (lexicon, small classifier, distilled toxicity model) returns block, allow, or canned reply. Hosted APIs or embedding-plus-linear models are details. Invariant: cheap path first, expensive model second.
Data model I sketch in LLM chat system design reviews
- Conversation has many messages
- Roles: user, assistant, system, tool
- Optional feedback row tied to assistant message id
Scale levers that interviewers expect you to name
- Stateless BFF and conversation API behind the load balancer
- Async workers if you add summarization or offline eval jobs
- Partition by
user_idorconversation_idhash - Autoscale the inference fleet on queue depth, not only HTTP RPS
Related system design posts
- Dating app system design with geo-sharded feeds
- Food delivery system design for search, drivers, and checkout
- Cross-platform libraries when the client is not only web
FAQ
What is LLM chat system design?
It is the end-to-end layout for a product where users send text, a model replies, and you persist turns, enforce limits, and gate abuse without melting cost or latency.
Where does moderation sit?
In front of the main model call on the hot path, with a fast classifier or rules layer so toxic or useless traffic never hits the big stack.
How do you size storage?
Start from DAU, conversations per user, messages per conversation, and bytes per row. If growth is real, plan sharding and retention on day one, not after the first outage.
Do thumbs-down ratings train the model live?
Usually no in v1. You store signals, then batch pipelines or human review decide what actually changes weights.
Close the loop before you leave the room
I re-read the functional and non-functional list and tick boxes. Multimodal input later means object storage, separate moderation models, and higher egress. Say that explicitly so scope does not creep mid-review.
